ENGINE & DRIVETRAIN
Cooling: Liquid
Cylinders Displacement: 925cc
Drive System Type: Isolated Xtreme Performance True On-Demand AWD/2WD
Engine Braking System (EBS): Not Equipped
Engine Type: 4-Stroke DOHC Twin Cylinder Turbocharged
Fuel System/Battery: Electronic Fuel Injection
Horsepower: 181 HP
Transmission/Final Drive: Automatic PVT P/R/N/L/H
DIMENSIONS
Bed Box Dimensions (L x W x H): 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm)
Box Capacity: 300 lb (136 kg)
Estimated Dry Weight: 1,983 lb (899 kg)
Fuel Capacity: 12 gal (45.4 L)
Ground Clearance: 16 in (40.6 cm)
Hitch Towing Rating: N/A
Overall Vehicle Size (L x W x H): 128 x 74 x 74.4 in (325 x 188 x 189 cm)
Payload Capacity: 730 lb (331 kg)
Wheelbase: 96 in (244 cm)
BRAKES
Front/Rear Brakes: 4-Wheel Hydraulic Disc with Triple-Bore Front and Dual-Bore Rear Calipers; Aluminum Top Hat Rotor
Parking Brake: Park In-Transmission
ADDITIONAL SPECIFICATIONS
Cargo System: Lock & RideĀ®
Doors: Full Door
Electronic Power Steering: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel with Tilt & Telescoping Adjustment; Ride Command Push Button Controls
Hitch Type: Not Equipped
Instrumentation: RIDE COMMANDā¢ 7ā Glove-Touch Display: Built-In GPS, Mapping, Vehicle-to-Vehicle with *Group Ride, Follow the Leader, & Messaging. Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets, Rockford Fosgate Premium Audio (Including 2 Tweeters, and 2 Front Speakers, and External 400W Amp) Dual-sweep Analog Dials w/ 4 in LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator
Lighting: Signature White LED, Low/High & Red LED Tail / Brake Lights; Front, Rear, and Interior Accent Lighting
Other Standard Features: RIDE COMMANDĀ® , High Output 900W Charging System, Polaris Pulse System, In-Dash Charge Port, 2 front DC Accy ports, Polaris P.A.S.S., Painted Aluminum Roof, Colored Toe Link, Mud and Rock Guards
Seat Type: Bolstered Bucket Seats with Driver 4-way adjustability (including 6″ front to back toolless seat slider with tilt adjustability) & Passenger tilt adjustability; Retractable Click-6 Harnesses
TIRES / WHEELS
Front Tires: 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15×7
Rear Tires: 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15×7
Wheels: Painted Cast Aluminum Rim with 5-Lug Pattern
SUSPENSION
Electronic Suspension Control System: Not Equipped
Front Shocks: Walker EvansĀ® 2.5ā Velocity Needle Shocks with 16-Position Adjustable Clickers
Front Suspension: Light Weight Boxed Dual A-Arm with 3 piece Stabilizer Bar and 27.0ā (68.6 cm) Usable Travel, 22.25ā (56.5 cm) Wheel Travel, Unitized Hubs
Rear Shocks: Walker EvansĀ® 3.0ā Velocity Needle Shock with 16-Position Adjustable Clickers
Rear Suspension: Tubular Trailing Arm with boxed gusseting and Toe Link, High Clearance Radius Rods, and Stabilizer Bar and 28.3″ (71.9cm) Usable Travel, 22.4″ (56.9 cm) Wheel Travel, Unitized Hubs
