SANY SY265C Excavator

SANY SY265C Excavator

The SANY SY265C is a high-production, 27-ton class crawler excavator built to dominate heavy construction, mass excavation, site clearing, and utility infrastructure projects. Powered by a high-torque Cummins QSB6.7 Tier 4 Final turbo diesel engine delivering 190 HP, the SY265C integrates SANY’s DOMCS (Dynamic Optimization Machine Control System) to intelligently balance engine power and hydraulic output, maximizing digging speed while keeping fuel consumption low.

Designed with a conventional tail swing and a fixed boom configuration, this machine delivers outstanding leverage, digging force, and over-the-side lifting stability. Equipped with a high-capacity 48″ heavy-duty bucket, a hydraulic thumb, and a Hydraulic Quick Coupler (HQC), the SY265C seamlessly handles heavy material placement, land clearing, and rapid tool changes. Inside the ROPS/FOPS certified cab, an air-heated suspension seat and integrated rear camera ensure high-visibility, all-weather comfort for long shifts on demanding job sites.

SANY SY265C Key Specifications & Features:

Engine & Performance

  • Engine Make/Model: Cummins QSB6.7 Tier 4 Final Turbo Diesel

  • Gross Power: 190 HP (142 kW) @ 2,000 RPM

  • Displacement: 6.7 L

  • Operating Weight: ~59,525 lbs (27,000 kg)

Working Capabilities

  • Max Dig Depth: 22′ 0″ (6,700 mm)

  • Max Reach at Ground Level: 33′ 7″ (10,225 mm)

  • Max Dumping Height: 22′ 1″ (6,735 mm)

  • Bucket Digging Force: ~41,815 lbf (186 kN)

Equipment & Hydraulics

  • Bucket: High-Capacity 48″ Heavy-Duty Bucket

  • Attachments & Hydraulics: Hydraulic Quick Coupler (HQC) and Hydraulic Thumb

  • Structure: Fixed Boom with Conventional Swing (No Blade configuration)

  • Under-Carriage: Heavy-duty Steel Tracks with full track guards for maximum traction and stability on rocky or uneven terrain

Operator Comfort & Safety

  • Cab Environment: Fully enclosed, quiet cab with automatic climate control (Heat/AC)

  • Seating: Premium Air-Heated Suspension Seat to reduce fatigue during cold-weather operations

  • Visibility & Safety: Large touchscreen display paired with an integrated Rear-View Camera for complete job site awareness
