Polaris Sportsman 850 Ultimate Trail

PolarisĀ® Sportsman 850 Ultimate Trail


  • Sportsman 850 Ultimate Trail

Your passion for trail riding has no limits and neither should your ATV. The Sportsman 850 Ultimate Trail pulls in the performance you need, with the style you want.

  • Explore The Sportsman 850 Line-Up

Meet the ATV that defined a category. The Sportsman 850 continues the tradition of do-it-all capability and toughness, with power that packs a punch and suspension to tame even the wildest terrains.

  • 78-Horsepower ProStar Engine with EFI
  • Industry-Leading On-Demand All-Wheel Drive
  • 11.5″ of Ground Clearance
  • Industry’s Largest 30 A.H. Battery
  • 360 lb Front and Rear Rack Capacity

Features may include:

  • Power Through The Elements

There’s nothing like the wide-open feeling you get from a Sportsman. The power, traction and ground clearance to tame the wildest terrain and always stay in control.

  • High-Output 78-Horsepower Engine
  • Industry-Leading On-Demand All-Wheel Drive
  • 11.5″ of Ground Clearance
  • Start Your Day With Confidence

Take charge with the assured capability of the 850. The industry’s largest cranking amp battery to get you started in extreme weather and force to tow the biggest hauls.

  • Powerful 30 A.H. Battery
  • 1,500 lb Towing Capacity
  • 360 lb. Front and Rear Rack Capacity
  • Thrill Rides Have No Curfew

Ride on your own terms, day or night with the added visibility of a third handlebar-mounted pod light. An easy-to-read backlit digital display system allows you to manage your speed or track your mileage with just a glance.


  • LED Pod & Lower Lighting
  • Dual High Clearance Arched A-Arms
  • Ultimate Series Front and Rear Bumper
  • 27″ Duro Tires and 14″ Aluminum Wheels
  • 3,500 lb Polaris HD Winch With Synthetic Rope
  • Multi-Select Electronic Power Steering (EPS)


Active Descent Control: Not Equipped

Cooling: Liquid

Cylinders Displacement: 2 / 850cc

Drive System Type: One Touch On-Demand AWD/2WD

Engine Braking System (EBS): Equipped

Engine Type: ProStar SOHC 4-Stroke Twin Cylinder

Fuel System/Battery: Electronic Fuel Injection / 400 CCA

Horsepower: 78 HP

Transmission/Final Drive: Automatic PVT P/R/N/L/H In-line Shifting


Estimated Dry Weight: 767 lbs (348 kg)

Front/Rear Rack: 120 lb (55 kg)/240 lb (110 kg)

Fuel Capacity: 5.25 gal (19.9 L)

Ground Clearance: 12 in (30.5 cm)

Overall Vehicle Size (L x W x H): 83.25 x 47.6 x 50.75 in (211.4 x 120.9 x 128.9 cm)

Payload Capacity: 575 lb (261 kg)

Person Capacity: 1

Seat Height: 37 in (94 cm)

Wheelbase: 53 in (134.6 cm)


Front/Rear Brakes: Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake

Parking Brake: Park In-Transmission / Lockable Hand Lever


Cargo System: Lock & Ride, 4 Gal (15 L) Front Dry Storage 2 Gal (8 L) Rear Storage

Front Suspension: Straight Dual A-Arm 9 in (22.9 cm) Travel

Hitch Towing Rating: 1,500 lb (680 kg)

Hitch Type: Standard 1.25 in (3.2 cm) Receiver

Instrumentation: All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet

Lighting: 50w High Beam, Dual 50w Low Beam Headlights, Dual LED Brakelights/Taillights

Other Standard Features: 4 Moveable Tie-Down Points, In Pod Battery Charge Port

Rear Suspension: Straight Dual A-Arm, Rolled IRS, 10.25 in (26 cm) Travel

RIDE COMMAND+: Available


Electronic Power Steering: Not Equipped

Front Tires: 26 x 8 CST

Rear Tires: 26 x 10 CST

Wheels: 14 in. (35.6 cm) Steel

Make Polaris
Model Sportsman 850 Ultimate Trail
Condition New
Engine 78HP
Listing Type For Sale
Location Klamath Falls
